CDM-625A Advanced Satellite Modem MN-CDM625A
Installation Revision 4
2–3
For information about custom rack enclosures, contact Comtech EF Data Product
Support.
• The CDM-625A CANNOT have rack slides mounted to the sides of the chassis.
Cooling fans and exhaust vents are provided here – air flow must not be
impeded. Comtech EF Data recommends that an alternate method of support is
provided within the rack, such as standard rack shelves or the optional Rear-
Mounting Support Bracket Kit. If there is any doubt, contact Comtech EF Data
Product Support.
Feature Description
1 Custom Rack Enclosure
2
CDM-625A Advanced Satellite
Modem
3 Standard Rack Shelving
4
Rack Enclosure Threaded Front
Mounting Rail (typical)
5
Modem Front Panel
6 User-supplied Screws
Figure 2-2. Install the modem Into a Rack Enclosure
