Comtech EF Data CDM-625A - BUC Parameters (L-Band Device)

CDM-625A Advanced Satellite Modem MN-CDM625A
Serial-based Remote Product Management Revision 4
8–59
8.5.8 BUC Parameters (L-Band Device)
Parameter
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to Query
BUC
Power Supply
enable
BPS=
Exception –
600L fn:
ODP=
1 byte, 0 or 1
Command or Query.
Sets or returns BUC Power Supply control in the form x. where:
0=Disable the BUC DC Power Supply
1=Enable the BUC DC Power Supply
BPS=
BPS?
BPS*
BPS#
BPS?
Exception –
600L Emulation:
ODP?
BPS=x
(see Description of
Arguments)
BUC
10 MHz
Reference
BFR=
Exception –
600L Emulation:
ODR=
1 byte
Command or Query.
Sets or returns BUC !0 MHz Reference the form x, where:
0=OFF
1=ON
BFR=
BFR?
BFR*
BFR#
BFR?
Exception –
600L Emulation:
ODR?
BFR=x
(see Description of
Arguments)
BUC
Current
Low Limit
BCL=
Exception –
600L Emulation:
ODL=
4 bytes
Command or Query.
Sets or returns BUC Current Low Limit, in the form xxxx, where:
xxxx=Value, in 100 mA increments, from 0000 thru 4000 mA
BCL=
BCL?
BCL*
BCL#
BCL?
Exception –
600L Emulation:
ODL?
BCL=xxxx
(see Description of
Arguments)
BUC
Current
High Limit
BCH=
Exception –
600L Emulation:
ODH=
4 bytes
Command or Query.
Sets or returns BUC Current High Limit, in the form xxxx, where:
xxxx=Value, in 100 mA increments, from 0000 thru 4000 mA
BCH=
BCH?
BCH*
BCH#
BCH?
Exception –
600L Emulation:
ODH?
BCH=xxxx
(see Description of
Arguments)
BUC
Address
BAD=
Exception –
600L Emulation:
OAD=
1 byte, 1 thru
15
Command or Query.
Sets or returns BUC Address in the form xx, where:
xx=Value 01-15.
NOTE: This command is only valid when the FSK is enabled.
BAD=
BAD?
BAD*
BAD#
BAD?
Exception –
600L Emulation:
OAD?
BAD=xx
(see Description of
Arguments)
BUC
Output Power
Enable
BOE=
Exception –
600L Emulation:
OOP=
1 byte, 0 or 1
Command or Query.
Sets or returns BUC Tx Carrier Output Power function in the form x, where:
0=OFF
1=ON
NOTE: This command is only valid when the FSK is enabled.
BOE=
BOE?
BOE*
BOE#
BOE?
Exception –
600L Emulation:
OOP?
BOE=x
(see Description of
Arguments)
BUC
DC
Current
N/A
4 bytes
Query only.
Returns BUC DC current in the form xxxx, where:
xxxx=Value, in mA, from 0000 and 9999.
NOTE: If not available, response is 0000.
N/A
BDC?
Exception –
600L Emulation:
ODC?
BDC=xxxx
(see Description of
Arguments)
BUC
Voltage
N/A
4 bytes
Query only.
Returns BUC Voltage in the form xx.x, where:
xx.x=Value, in volts, from 00.0 thru 64.0
N/A
BDV?
Exception –
600L Emulation:
ODV?
BDV=xx.x
(see Description of
Arguments)
BUC
Output Power
Level
N/A
4 bytes
Query only.
Returns BUC Output Power Level in the form xx.x, where:
xx.x=Value, in dBm.
NOTE: Returns xxxx when FSK is not enabled.
EXAMPLE: <0/BOL? >0000/BOL=37.4
N/A
BOL?
Exception –
600L Emulation:
OOL?
BOL=xx.x
(see Description of
Arguments)
