CDM-625A Advanced Satellite Modem MN-CDM625A
Front Panel Operation Revision 4
6–73
Press ENTER.
CONFIG: IP ANT PTP: Transport=Unicast
PTP Unicast Master = 192.012.002.021
Sync Rate = 1 Message every 2 seconds
Once you select Unicast, use the
◄ ►arrow keys to navigate between the top and bottom line.
On the top line – To edit the PTP Unicast Master IP Address, use the
◄ ►arrow keys to select a
digit, and then use the
▲▼ arrow keys to change that digit. Press ENTER.
On the bottom line – Use the
▲▼ arrow keys to select the synchronization interval of packets
per second for messages sent from the Master to the Slave. Available selections are:
•
•
1 message every 2 seconds
•
•
•
•
•
•
You may use Sync Rate only when the Grandmaster is LAN port and the Transport
Mode is Unicast.
6.2.1.13.5 CONFIG: IP PortMonitor
Port Monitor: Enabled Source=Port 2
Destination=Port 3 Direction=Both ()
Port monitoring allows a port’s ingress and/or egress traffic to be mirrored on another port. This
is useful for link monitoring or packet capturing without interrupting live traffic.
Use the
◄ ►arrow keys to move the cursor to the function; then, use the ▲▼ arrow keys to set
the function parameter. Press ENTER.
Valid selections are:
Function Setting
Port Monitor Enabled or Disabled.
Source WAN, Port 1, Port 2, Port 3, or Port 4.
Destination Port 1, Port 2, Port 3, or Port 4. (You may not select the active “Source” Port.)
Direction Ingress, Egress, or Both.
