8.5.4 Unit Parameters
Parameter
Command
(Instruction
& Qualifier)
Length of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to Query
Local/
Remote Status
LRS=
1 byte, 0 thru 3
Command or Query.
Sets or returns the user’s Local/Remote status in the form x, where:
0=Local
1=Serial Remote (RS-232/RS-485)
2=Reserved
3=Ethernet Remote
EXAMPLE: <0/LRS=1 (selects Serial Remote)
LRS
LRS?
LRS*
LRS#
LRS?
LRS=x
(see Description of
Arguments)
Modem
Emulation
EMU=
1 byte, 0 thru 2
Command or Query.
The CDM-625A is designed to be a ‘drop-in’ replacement for the CDM-600 or CDM-600L modems. This parameter
permits the CDM-625A modem emulate CDM-600/L operation.
The format for the argument is x, where x is:
0=full capability CDM-625A modem (DEFAULT)
1=CDM-600 modem emulation
2=CDM-600L modem emulation
Note: For complete modem emulation, all parameters, including the EID (equipment ID) must be that of the modem it is
emulating.
EMU=
EMU?
EMU*
EMU#
EMU?
EMU=x
(see Description of
Arguments)
Front Panel
Lockout
FPL=
1 byte, numeric
Command or Query.
Sets or returns the state of front-panel lockout in the form x, where:
0=no lockout
1=front panel lockout active.
NOTE: Disable the lockout by either FPL=0, or by setting into local mode using LRS=0.
FPL=
FPL?
FPL*
FPL#
FPL?
FPL=x
(see Description of
Arguments)
Software
IMG=
1 byte, 1 or 2
Command or Query.
Sets or returns the active firmware image in the form x, where:
1=Bulk Image #1 currently active
2=Bulk Image #2 currently active
IMG=
IMG?
IMG*
IMG#
IMG?
IMG=x
(see Description of
Arguments)
Circuit ID
String
CID=
40 bytes
Command or Query.
Sets or returns the user-defined Circuit ID string, which is a fixed length of 40 characters.
Valid characters include: Space ( ) * + – , . / 0-9 and A-Z
CID=
CID?
CID*
CID#
CID?
CID=x
(see Description of
Arguments)
RTC Date
DAY=
6 bytes
Command or Query.
Sets or returns a date in the form ddmmyy (European format), where
dd=day of the month (01 to 31)
mm=month (01 to 12)
yy=year (00 thru 99)
EXAMPLE: <0/DAY=240457 (April 24, 2057)
DAY=
DAY?
DAY*
DAY#
DAY?
DAY=ddmmyy
(see Description of
Arguments)
RTC Time
TIM=
6 bytes
Command or Query.
Sets or returns a time from midnight, in the form hhmmss, where:
hh=hours (00 thru 23)
mm=minutes (00 thru 59)
ss=seconds (00 thru 59)
EXAMPLE: <0/TIM=231259 (23 hours:12 minutes:59 seconds – 11:12:59 P.M.)
TIM=
TIM?
TIM*
TIM#
TIM?
TIM=hhmmss
(see Description of
Arguments)
