CDM-625A Advanced Satellite Modem MN-CDM625A
Front Panel Operation Revision 4
6–95
6.2.6.5 Utilities: Redundancy
Redundancy:
Traffic-IP-Addr/Range 1:1 1:N
Use the
▲▼ arrow keys to select Traffic-IP-Addr/Range, 1:1, or 1:N. Press ENTER.
6.2.6.5.1 Utilities: Redundancy Traffic-IP-Addr/Range
Traffic IP address/Range
192.168.001.001/24 ()
To edit the Traffic IP Address and range, when the modem is part of a 1:1 or 1:N redundancy
application: First, use the
◄ ►arrow keys to select a digit, and then use the ▲▼ arrow keys to
change that digit. Press ENTER.
6.2.6.5.2 Utilities: Redundancy 1:1
Press ENTER key to force Unit into
Standby (1:1 only)
For use when the modem is part of a 1:1 redundancy application (e.g., via a CRS-170A L-Band or
CRS-180 70/140 MHz 1:1 Redundancy Switch) and this unit is currently Online, press ENTER to
cause the unit to switch to Standby (i.e., go Offline).
6.2.6.5.3 Utilities: Redundancy 1:N
1:N Mode: (use with CAUTION!)
Disabled (Enable, Disable) ()
For use when the unit is part of a 1:N redundant application (e.g., via a CRS-300 1:10
Redundancy Switch). Use the
▲▼ arrow keys to select 1:N Mode operation as Enable or
Disable. Press ENTER.
When the unit is connected to a 1:N switch, a red LED located on the rear panel
labeled “1:N Active!” indicates that caution is required, as there may be DC voltages
and other control signals present on certain pins on the 25-pin ‘Data Interface’
connector.
