CDM-625A Advanced Satellite Modem MN-CDM625A
Front Panel Operation Revision 4
6–58
6.2.1.13.3 CONFIG: IP  Setup
IP Setup: Mode WAN PerPortCnfg DDMgmtPt
MAC-Lrng Rad VLAN QoS Stats FrmSize ()
Use the
◄ ►arrow keys to select a parameter. Press ENTER.
6.2.1.13.3.1 CONFIG: IP  IP Setup: Mode
Working Mode: Router Point to Point
(ManagedSwitch,R-PtoP, R-MPHub,R-MPRm)()
Use the
◄ ►arrow keys to select ManagedSwitch, R-PtoP (Router Point-to-Point), R-MPHub
(Router Multipoint-to-Hub), or R-MPRm (Router Multipoint-to-Remote). Press ENTER.
If the optional IP Packet Processor card is either not installed or installed but
disabled, the mode is “Fixed at Managed Switch Mode”.
6.2.1.13.3.2 CONFIG: IP  IP Setup: WAN
WAN: Buffer Length = 240ms
Avg Buffer Fill State = 00% ()
On the top line – Use the
▲▼ arrow keys to edit the WAN Buffer Length. Press ENTER. Valid
settings are:
Minimum
Maximum
Step Size (Increment)
20ms
400ms
20ms
Press ENTER. Packets are dropped when the buffer is exceeded.
On the bottom line (read-only) – The percentage of the Average WAN Buffer Fill State displays
across a 4-second duration.
When you install and enable the optional IP Packet Processor card, the WAN
submenu is non-functional and displays as follows:
WAN: Buffer Length = N/A due to PktP
Avg Buffer Fill State = xx% ()
