Comtech EF Data CDM-625A - Approvals; Miscellaneous

CDM-625A Advanced Satellite Modem MN-CDM625A
Introduction Revision 4
1–34
1.4.9 Miscellaneous
Front Panel
Tactile keypad, 6 keys (up, down, left, right, ENTER, CLEAR)
Vacuum Fluorescent Display (blue) – two lines @ 40 characters/line
Loopbacks
Internal IF loopback, RF loopback, digital loopback, and inward/outward loopback
Fault relays
Hardware fault, Rx and Tx Traffic Alarms, Open Network Backward Alarms
Type: Form C Contacts. Rating: Up to ±50 volts, maximum 0.5 Amp
M&C Interface
EIA-232 and EIA-485 (addressable multidrop, 2-wire or 4-wire) or Ethernet (10/100 BaseT)
M&C Software
Serial comms, SNMP, Telnet, HTTP (Web Server)
Firmware update
FTP protocol via Ethernet port
Dimensions
1RU high, 17.65 inches (448 mm) deep
Weight
10.5 lbs (4.8 kg) maximum (All option cards and 48V BUC supply installed)
AC consumption
48 watts (typical, TPC/LDPC Codec module installed), 68 watts (maximum)
280 watts (typical, TPC/LDPC Codec module and 48 volt BUC supply installed, 300 watts (max)
AC operating voltage
100-240 VAC Nominal - autosensing
90-264 VAC Maximum
DC consumption (option)
As above (AC consumption)
DC operating voltage
20-60 VDC Nominal
36-60 VDC Maximum
Operating temperature
32°-122°F (0°-50°C)
‘ER’ VERSION: 32°-140°F (0°-60°C)
1.4.10 Approvals
“CE” as follows:
EN 55022 Class B (Emissions)
EN 50082-1 (Immunity)
EN 60950-1 (Safety)
EN 61000-3-2
EN 61000-3-3
EN 61000-4-2
EN 61000-4-4
EN 61000-4-5
EN 61000-4-6
EN 61000-4-8
EN 61000-4-9
EN 61000-4-11
EN 61000-4-13
FCC Federal Communications Commission Federal Code of Regulation FCC Part 15, Subpart B.
