6.2.2.2 SELECT: TEST  BERT
BERT: Config Monitor
()
Use the
◄ ►arrow keys to select Config or Monitor. Press ENTER.
6.2.2.2.1 SELECT: TEST  BERT  Config
BERT Tx:Off Pattern=2047 ErrIns=Off
Cnfg Rx:Off Pattern=2047 ()
Use the
◄ ►arrow keys to select a BERT configuration parameter, and then use the ▲▼ arrow
keys to select a parameter setting.
Available settings are:
Option
Setting
Tx/Rx Options
Off or On
ErrIns Options Off or 10E-3
Pattern Options
Space, Mark, 1:1, 1:2, 63, 511, 2047, 2047R, MIL188, 2
15
-1, 2
20
-1, 2
23
-1
6.2.2.2.2 SELECT: TEST  BERT  Monitor
BERT Monitor: Errs=0000000 Sync: OK
BER=0.0E-07 Restart
Press ENTER to restart the BERT Monitor.
6.2.2.3 SELECT: TEST  CnC-APC-Monitor
CNC-APC: BER=N/A Reset FER=N/A Reset
()
The test results provided on this screen are:
Test
Description
BER
Bit Error Rate
FER Frame Error Rate
To restart either Test, use the
◄ ►arrow keys to select (BER) Reset or (FER) Reset. Press ENTER.
