CDM-625A Advanced Satellite Modem MN-CDM625A
Front Panel Operation Revision 4
6–100
6.2.7 SELECT: ODU Menu Branch (Summary Only)
See Chapter 10. CDM-625A ODU (TRANSCEIVER, BUC, LNB) OPERATION for
complete details about this product-specific menu branch.
ODU: BUC:PwrSupply+Ref
LNB:PwrSupply+Ref FSK-control ()
Depending on 70/140 MHz or L-Band operation: Use this menu branch to monitor and control a
standalone or redundant Comtech EF Data RF Transceiver (CSAT-5060 or KST-2000A/B) or LPOD
BUC, when connected.
6.2.8 SELECT: FAST Menu Branch
The display example as shown here depicts a unit shipped with the Two- channel
Audio Drop hardware option installed. If this hardware is not included, ‘Audio’ does
not appear on the bottom line.
FAST: Options Demo-Mode CnC
Baseboard S/N 123456789 HW Rev1.X Audio
FAST (Fully Accessible System Topology) allows you to enable new options in the modem. Use
the
◄ ►arrow keys to select Options, Demo-Mode, or CnC. Press ENTER.
6.2.8.1 FAST: Options
FAST options: View Options
Set Register1 Set Register2 ()
You can access the FAST options via three separate internal EEPROM registers. Each register
requires its own FAST access code. Use the
◄ ►arrow keys to select View Options, Set
Register1, or Set Register2. Press ENTER.
6.2.8.1.1 FAST: Options  View Options
FAST: View options: 01 ()
Base 5 Mbps data rate installed
Use the
▲▼ arrow keys to scroll through the available options. The modem identifies each
selected FAST option as “installed” or “not installed”.
