CDM-625A Advanced Satellite Modem MN-CDM625A
Front Panel Operation Revision 4
6–55
6.2.1.13 CONFIG: IP
IP Config: Addresses SNMP Setup ANT
PortMonitor AccessList PktP-Enable()
Use the
◄ ►arrow keys to select a parameter. PktP-Enable displays only when you install the
the optional IP Packet Processor card.
Press ENTER to continue.
6.2.1.13.1 CONFIG: IP  Addresses
IP Addresses: MAC Gateway
Addr/Range ()
Use the
◄ ►arrow keys to select MAC, Gateway, or Addr/Range. Press ENTER.
CONFIG: IP  Addresses  MAC
Ethernet MAC Address:
00-06-B0-00-01-06 (read-only)
This screen displays the read-only unit MAC address.
Press ENTER or CLEAR to return to the previous menu.
CONFIG: IP  Addresses  Gateway
Ethernet IP Gateway:
192.168.001.002 ()
Edit the IP Gateway Address for the Ethernet M&C port for this unit by using the
◄ ►arrow keys
to select a digit. Then, use the
▲▼ arrow keys to change that digit. Press ENTER.
CONFIG: IP  Addresses  Address/Range
Ethernet IP Address/Range:
192.168.001.002/24 ()
Configure the IP Address for the Ethernet M&C port for this unit by using the
◄ ►arrow keys to
select a digit. Then, use the
▲▼ arrow keys to change that digit. Press ENTER.
