CDM-625A Advanced Satellite Modem MN-CDM625A
Front Panel Operation Revision 4
6–69
Define Port Priority by using the ◄ ►arrow keys to select the port (P1, P2, P3, or P4), and then
using the
▲▼ arrow keys to designate a priority from 1 to 4 (with Priority 4 being the highest).
CONFIG: IP  IP Setup: QoS L3 QoS
When the optional IP Packet Processor card is either not installed or installed but disabled, and
L3 QoS is selected, this menu is disabled and appears as follows:
L3 QoS=Off
(Fixed at Off) ()
Otherwise, when the optional IP Packet Processor card is installed and enabled, the L3 QoS
menu appears as follows:
L3 QoS=Off
(Off,Max/Prio,MinMax,DiffServ) ()
Use the
▲▼ arrow keys to set the L3 QoS operational priority. Press ENTER.
Valid settings are:
Setting Function
Off
QoS disabled.
Max/Prio
(Maximum priority only) Provides multi-level traffic prioritization with the ability to limit
maximum traffic per priority class.
MinMax
(Minimum/Maximum priority) Provides a Committed Information Rate (CIR) to each
user-defined class of traffic with the ability to allow a higher burstable rate depending
on availability.
DiffServ
(DiffServ priority only) Industry-standard method of providing QoS, enabling
seamless co-existence in networks that implement DiffServ.
6.2.1.13.3.9 CONFIG: IP  IP Setup: Stats
IPstats: Port x In Out ()
Unicasts: 00000003 00000023 Clr:N
This screen displays IP traffic statistics for both the In (Ingress) and Out (Egress) directions. Use
the
◄ ►arrow keys to navigate to the proper line, in this order:
First, on the top line – Use the
▲▼ arrow keys to select the bottom-line IP Stats Type as WAN,
Ports 1 through 4, HDLC FPGA, or Management. (“In” and “Out” are column labels for the
bottom line parameters and are not selectable.)
Next, on the bottom line – Use the
▲▼ arrow keys to view the desired statistical parameter.
