Comtech EF Data CDM-625A - Home > Network > Ethernet Ports > Ethernet Port

CDM-625A Advanced Satellite Modem MN-CDM625A
Telnet Command Line Interface (CLI) Operation Revision 4
9–42
9.3.4.1.1 Home > Network > Ethernet Ports > Ethernet Port #
Open the nested Ethernet Port 1 through Ethernet Port 4 pages from the scrollable Home >
Network> Ethernet Ports page. Each page contains the following options:
Hot
Key
Dialog Window Option Entry
A Ethernet Ports Speed
Use the ↑↓ arrow keys to select:
•
Auto
•
Full 100 Mbps
•
Half 100 Mbps
• Full 10 Mbps • Half 10 Mbps
B Ethernet Ports Pause Flow Control Use the ↑↓ arrow keys to select Off or On
C Ethernet Port Mode Use the ↑↓ arrow keys to select Trunk or Access
D Ethernet PVID Enter a value from 1 to 4095
E
Ethernet Port Priority
Enter a priority value from 1 to 4
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Ethernet Ports
page.
