8.5.5 Bulk Configuration Strings
NOTE: In order to completely get/set the configuration of the modem, the following commands must be queried/set:
• MGC
• OGC (L-Band Only)
• Drop and Insert (specified in MGC):
o DNI (Open Network Drop and Insert );
o DIC (Closed Network DNI++ Drop and Insert);
o QDI (Quad Drop and Insert), one for each active port up to a maximum of four.
Parameter
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
(Instruction &
Qualifier)
Response to Query
Configuration
numerical
entries, fixed
values, and
delimiters
Command or Query.
Global Configuration of CDM625, in the form shown in the Response to Query column (to right) where:
MGC?
MGC*
MGC#
MGC?n (where
n=0 thru 9.
Returns the MGC
portion of 1 of 10
stored
configurations)
DD.DDDGYRMVSPP.
PBaaa.aaCXIKNZffff.fff
fddddd.dddgyrmvsww
wcll.lbbbbbiknzOEEEE
TeeeeeeeeeeeeeWAL
QUHHHHhhhhJJJJjjjja
bcdefxxxxxxxxxxrrrrr.rr
rsssss.ssshgkpmnnntt
uuu.uuu.uuu.uuu.uuvv
v.vvv.vvv.vvvxGHIJKw
AAABBBCCCeexEFG
GGH
DDDDD.DDD=TX Data Rate
G=Tx FEC Type
Y=Tx Reed-Solomon Type
R=Tx FEC Rate
M=Tx Modulation Type
V=Tx Spectrum Inversion
S=Tx Scrambler State
PP.P Tx Power Level
B=AUPC Enable
aaa.aa=AUPC Parameter Setup
C=Tx Clock Source
X=Tx Carrier State
I=Tx Interface Type
K=Tx Ternary Code
N=Tx Framing Mode
Z=Tx Clock Invert*
ffff.ffff=Rx Frequency*
ddddd.ddd=Rx Data Rate
g=Rx FEC Type
y=Rx Reed-Solomon Type
r=Rx FEC Rate
m=Rx Modulation Type
v=Rx Spectrum Inversion
s=Rx Scrambler State
www=Rx Sweep Width*
c=Rx Clock Source
ll.l=Eb/No Alarm Point
same as TDR
same as TFT
same as TRS
same as TCR
same as TMD
same as TSI
same as TSC
same as TPL
same as AUP
same as APP
same as TCK
same as TXO
same as TIT
same as TTC
same as TFM
same as TCI
same as RFQ
same as RDR
same as RFT
same as RRS
same as RCR
same as RMD
same as RSI
same as RDS
same as RSW
same as RCK
same as EBA
