CDM-625A Advanced Satellite Modem MN-CDM625A
Front Panel Operation Revision 4
6–86
6.2.3.8 Monitor: CnC-Parameters
CnC-Params:PwrRatio=-04.1dB PSDR=+01.9dB
Freq-offset=-123.4kHz Delay=123.4ms
When enabled and locked, the screen displays the CnC performance data. This read-only display
updates once every second.
When CnC-APC is active, the PwrRatio and PSDR fields will display as ‘AUTO’.
6.2.3.9 Monitor: IP Statistics
IPstats: Port x In Out ()
Unicasts: 00000003 00000023 Clr:N
This screen is identical to and displays the same performance information as the screen shown
in Sect. 6.2.1.13.3
CONFIG: IP Setup Stats.
