7.5.4.2.2 Admin | SNMP
• Chapter 6. FRONT PANEL OPERATION
• Sect. 7.3 SNMP INTERFACE
The Administrator must use this page to set and return administration information for the
CDM-625A SNMP (Simple Network Management Protocol) feature.
Figure 7-5. Admin | SNMP page
SNMP
• Simple Network Management – Use the drop-down list to select as Disabled or Enabled.
• Enable Authentication Trap – Use the drop-down list to select as Disable or Enable.
• Assign up to two SNMP Trap IP Addresses in the form xxx.xxx.xxx.xxx.
• Trap Version – Use the drop-down list to select SNMPv1 or SNMPv2.
• SNMP Read/Write/Trap Community Strings, SNMP Contact/Name/Location – Create or
edit these alphanumeric text strings as follows:
Setting Factory Default Typical Parameters
SNMP Read Community String
public
The Read, Write, and Trap Community Strings
can be any alphanumeric combination with a
maximum length of 4 to 15 characters.
SNMP Write Community String
private
SNMP Trap Community String
comtech
SNMP Contact
N/A
The SNMP Contact, Name, and Location strings
can be any alphanumeric combination with a
maximum length of 0 to 20 characters.
SNMP Name
N/A
SNMP Location
N/A
• CDM-625 MIB Compatibility – Use the drop-down list to select as Disabled or Enabled.
This feature is available only when the optional IP Packet Processor is installed and enabled.
When enabled, you may use CDM-625 MIBs to monitor and control features that are
common to both the CDM-625 and CDM-625A/AL modems.
