6.2.4.6 Info: Clocks
Clocks:Tx=Int(SCT) CEX=RxEnable E1-unbal
Rx=Int(SCT) Buffer=00016bytes REF=Int10
This screen displays information for Tx Clock, G.703 Clock Extension, Rx Clock, Reference, and
Buffer.
6.2.4.7 Info: EDMAC
EDMAC Function= On
EDMAC Mode= Master EDMAC Addr= 0020
This screen indicates whether or not EDMAC is enabled. When EDMAC is enabled, it displays the
EDMAC Mode and Address.
6.2.4.8 Info: Drop
Drop Type= CH:1
E1-CCS TS:01
This screen displays the Drop Type and channel allocations.
When in QDI (Quad Drop & Insert) Mode, this screen displays the same information
as the CONFIG: D&I

Drop menu.
6.2.4.9 Info: Insert
Insert Type= CH:1
E1-CCS TS:01
This screen displays the Insert Type and channel allocations. Press ENTER or CLEAR to return to
the previous menu.
When in QDI (Quad Drop & Insert) Mode, this screen displays the same information
as the CONFIG: D&I

Drop menu.
