CDM-625A Advanced Satellite Modem MN-CDM625A
Front Panel Operation Revision 4
6–64
CONFIG: IP IP Setup: VLAN PortMode Port#
Where # denotes the selected Port:
Port #: Port Mode= Trunk
PVID=N/A ()
Use the
◄ ►arrow keys to select the operation parameter. Then, use the ▲▼ arrow keys to
select Trunk or Access:
• When you select Trunk as the Port Mode, VLAN ID (PVID) does not apply. On the bottom
line of the display, the selected port’s PVID will display as
PVID=N/A.
• Otherwise, when you select Access as the Port Mode you must configure the VLAN IDs
(PVIDs). Edit the PVID by using the
◄ ►arrow keys to select a digit. Then, use the ▲▼
arrow keys to change that digit, and then press ENTER. You may create a PVID in the range
from 0001 to 4095. The default is 0001.
Hold down the ▲ ▼ arrow keys to quickly scroll between 0001 and 4095.
CONFIG: IP IP Setup: VLAN VLAN-Table
VLAN Table:
View/Edit/Delete Add-Entry ()
The VLAN table supports up to 32 entries. Use the
◄ ►arrow keys to select View/Edit/Delete or
Add-Entry. Press ENTER.
CONFIG: IP IP Setup: VLAN VLAN-Table View / Edit / Delete
VLAN ID:0001 P1:Filtered P2:Untagged
P3:Tagged P4:Untagged ACT=None(N,E,D)
Do these steps to view, edit, or delete existing VLAN IDs:
• First, use the
◄ ►arrow keys to select the desired parameter:
o VLAN ID – Selects the tabulated VLAN ID. After selecting VLAN ID, use the
▲▼ arrow
keys to scroll through the available VLAN IDs.
o ACT – Choose an action to undertake for the selected VLAN ID – NONE (default), Edit, or
Del (Delete).
o P1 (Port1) through P4 (Port4) – With ACT=Edit active, you may update the selected
port’s behavior attributes, as assigned under the selected VLAN ID.
