CDM-625A Advanced Satellite Modem MN-CDM625A
Ethernet-based Remote Product Management Revision 4
7–15
Factory Default User Name / Password
Read Only monitor / 1234
Name and Password fields can be any
alphanumeric combination with a
maximum length of 10 characters.
Read/Write opcenter / 1234
Admin comtech / comtech
• SMTP Server – Specify the mail server IP Address from where e-mail may be sent.
• SMTP Domain Name / Destination – The Administrator can assign the SMTP Domain Name
and Destination.
o SMTP Domain Name – Specify the domain of the e-mail server (usually found to the
right of the '@' symbol in an e-mail address).
o SMTP Domain Destination – Specify the e-mail recipient name (usually found to the left
of the '@' symbol in an e-mail address).
Host Access List
• IP (#) / Mask – The Host Access List allows a user to define which remote clients can connect
when the Access List is Enabled. Each entry allows a user to specify an IP Address and a
subnet mask to define a unique class of machines that are allowed access.
For example, if a user wanted to grant access to a PC with an IP Address of 10.10.10.1 and
any PC on a subnet of 192.168.10.XXX, and then the Access List would be defined as:
IP 1 / Mask – 10.10.10.1/32
IP 2 / Mask – 192.168.10.0/24
The check box before the IP (#) / Mask must be checked in order for that list entry
to take effect.
• Access List – The Access List allows a user to grant access via HTTP and SNMP to a defined
list of client machines.
Use the drop-down to select Enable or Disable. If Disable is selected, then any client
machine will be able to connect via HTTP and SNMP.
Click [Submit Admin] to save.
RADIUS (Remote Authentication Dial In User Service)
Appendix T. CDM-625A RADIUS CLIENT
RADIUS operation is available only when the CDM-625A operating mode is set to IP
or IP-ACM.
