CDM-625A Advanced Satellite Modem MN-CDM625A
Serial-based Remote Product Management Revision 4
8–13
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to Query
…Tx FEC
Code Rate
(cont)
y=VersaFEC-2 ModCod 29 – 32-ARY 0.684
z=VersaFEC-2 ModCod 30 – 32-ARY 0.708
“=VersaFEC-2 ModCod 31 – 32-ARY 0.733
&=VersaFEC-2 ModCod 32 – 32-ARY 0.757
@=VersaFEC-2 ModCod 33 – 32-ARY 0.782
[=VersaFEC-2 ModCod 34 – 32-ARY 0.801
]=VersaFEC-2 ModCod 35 – 32-ARY 0.831
{=VersaFEC-2 ModCod 36 – 32-ARY 0.855 (Long Block only)
}=VersaFEC-2 ModCod 37 – 32-ARY 0.879 (Long Block only)
Depending on FEC type, not all of these selections will be valid.
EXAMPLE: <0/TCR=1 (selects Rate 3/4)
Tx Data Rate
TDR=
9 bytes
Command or Query (Query only in ACM).
Sets or returns Tx Data rate in the form xxxxx.xxx, where:
xxxxx.xxx=Value, in kbps, from 18 kbps to 25 Mbps
Resolution=1 bps
NOTES:
1) Additional auxiliary G.703 sub-rates are available, selected using:
00512.AUX 01024.AUX 02048.AUX
2) The connectors used for the Aux rates are IDI/DDO.
3) These Aux rates are not available with Drop & Insert or IDR.
4) Read-only if Framing Mode is Quad Drop & Insert (TFM=8).
Data rate is set by assigning the number of channels on each port.
5) Read-only if Modulation Type is a ‘Reserved’ type
EXAMPLE: <0/TDR=02047.999 (selects 2047.999 kbps)
TDR=
TDR?
TDR*
TDR#
TDR?
TDR=xxxxx.xxx
(see Description of
Arguments)
Tx
Symbol Rate
TSR=
9 bytes, numeric
Query only (Command or Query in IP-ACM or VersaFEC-2 ACM).
Allows remote access to the Tx symbol rate in the form ddddd.ddd.
NOTE: Symbol Rate range in IP-ACM is from 37 ksym/sec to 4100 ksym/sec
Symbol Rate ranges in VersaFEC-2 ACM Short Block is from 37 ksym/sec to 1000 ksym/sec
Symbol Rate ranges in VersaFEC-2 ACM Long Block is from 37 ksym/sec to 125000 ksym/sec
TSR?
TSR=
TSR*
TSR#
TSR?
TSR=ddddd.ddd
(see Description of
Arguments)
Tx Frequency
TFQ=
9 bytes
Exception –
600 Emulation
8 bytes
Command or Query.
Sets or returns Tx Frequency in the form xxxx.xxxx, where:
70/140 Unit range is from 50 MHz to 180 MHz, and
L-Band Unit (FAST Option) range is from 950 MHz to 2250 MHz
Resolution=100Hz.
EXAMPLE: <0/TFQ=0950.9872
TFQ=
TFQ?
TFQ*
TFQ#
TFQ?
TFQ=xxxx.xxxx
Exception –
600 Emulation:
TFQ=xxx.xxxx
Tx
Data Invert
TDI=
Exception –
600/L Emulation:
ITD=
1 byte, 0 or 1
Command or Query.
Sets or returns Invert Transmit Data in the form x, where:
0=Normal
1=Inverted
EXAMPLE: <0/TDI=1 (selects TX Data Invert
TDI=
TDI?
TDI*
TDI#
TDI?
Exception –
600/L Emulation:
ITD?
TDI=x
(see Description of
Arguments)
Tx Sub-Mux
on/off
TMX=
1 byte, 0 or 1
Command or Query.
Sets or returns Tx Sub-Mux in the form x, where:
0=Off
1=On
TMX?
TMX=
TMX*
TMX#
TMX?
TMX=x
(see Description of
Arguments)
