CDM-625A Advanced Satellite Modem MN-CDM625A
Serial-based Remote Product Management Revision 4
8–31
Parameter
Command
(Instruction
& Qualifier)
Length of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to Query
…Retrieve next
five unread
Stored Events
(cont.)
C=Fault Code number, as in FLT? or Info Code, which may be:
0=Power Off
1=Power On
2=Log Cleared
3=Global Config Change
4=Redundancy Config Change
5=Fractional CnC License is expiring.
6=Time Limited CnC License is expiring.
7=Fractional CnC is in use.
ddmmyy=date stamp.
hhmmss=time stamp.
NOTES:
1) If there are less than five retrievable events, the remaining positions are padded with zeros.
2) If there are no new events, the response is RNE*.
Clear All
Stored Events
CAE=
None
Command only.
This command takes no arguments. Forces the modem to clear the firmware events log.
EXAMPLE: <0/CAE=
CAE=
CAE?
CAE*
CAE#
N/A
N/A
Initialize Stored
Events Pointer
IEP=
None
Command only.
Resets internal pointer to allow RNE? queries to start at the beginning of the stored events log.
IEP=
IEP#
N/A
N/A
Statistics
Sample Interval
SSI=
1 byte, numerical
Command or Query.
Sets or returns the sample interval for the Statistics Logging Function in the form x, where:
x=0 thru 9 in 10 minute steps.
NOTE: Set this parameter to 0 thru disable the statistics logging function.
EXAMPLE: <0/SSI=3 (interval is set at 30 minutes)
SSI=
SSI?
SSI*
SSI#
SSI?
SSI=x
(see Description of
Arguments)
Number of
Unread stored
Statistics
N/A
3 bytes
Query only.
Returns the number of stored statistics that remain unread over remote control, in the form xxx, where xxx=000-255.
EXAMPLE: <0/NUS? >0/NUS=187
N/A
NUS?
NUS=xxx
(see Description of
Arguments)
Retrieve next
five unread
Stored
Statistics
N/A
135 bytes
Query only.
Returns the oldest five stored Statistics that have not yet been read, in the form [CR]sub-body[CR]sub-body[CR]
sub-body[CR]sub-body[CR]sub-body where:
• For all non-ACM modes, the statistics sub-body is defined as AA.ABB.BC.CD.Dddmmyyhhmmss where:
AA.A=Minimum Eb/No during sample period.
BB.B=Average Eb/No during sample period.
C.C=Maximum Tx Power Level Increase during sample period.
D.D=Average Tx Power Level Increase during sample period.
ddmmyy=date stamp.
hhmmss=time stamp.
• In VersaFEC ACM (IP-ACM) mode, the statistics sub-body is defined as AA.ABB.BC,DE,Fddmmyyhhmmss,
where:
AA.A=Minimum SNR during sample period.
BB.B=Average SNR during sample period.
C=IP-ACM Rx ModCod that was current at time the statistic entry was logged.
D=Maximum Rx ModCod in hex during sample period.
E=Minimum Rx ModCod in hex during sample period.
N/A
RNS?
RNS=[CR]sub-
body[CR]sub-
body[CR]
sub-body[CR]sub-
body[CR]sub-body
(see Description of
Arguments)
