Parameter
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to Query
Drop & Insert
DNI=
51 bytes
Command or Query. (D&I only)
Sets or returns D&I in the form ddddddddddddddddddddddddtiiiiiiiiiiiiiiiiiiiiiiiiTL, where:
25 bytes of Drop information (ddddddddddddddddddddddddt) where:
d=24 channels (bytes) defining Drop Timeslot information
t=Drop type: 0=T1-D4, 1=T1-ESF, 2=E1-CCS, 3=E1-CAS, as DTY
25 bytes of Insert information (iiiiiiiiiiiiiiiiiiiiiiiiT) where:
i=24 channels (bytes) defining Insert Timeslot infromation
T=Insert type: 0=T1-D4, 1=T1-ESF, 2=E1-CCS, 3=E1-CAS, as ITY
Typical for Drop or Insert Timeslot definition:
0=Unused
z=Timeslot 0 (zero)
1-9=Timeslots 1 through 9
A=Timeslot 10 through V=Timeslot 31
L=D&I Internal Loop: 0=OFF, 1=ON
EXAMPLE: <0/DNI=123456789ABC0000000000003123456789ABC00000000000031
(Drop channels 1-12 using timeslots 1-12, and unused channels 13-24. Same for Insert. E1-CAS, D&I types,
Internal Loop ON).
NOTE: If framing is D&I and data rate is 1920 kbps and DNI Type is E1-CCS or E1-CAS, then channels cannot be
programmed (i.e. FIXED CHANNEL MODE).The DNI? response will display all ‘x’ in the time-slot positions.
DNI=
DNI?
DNI*
DNI#
DNI?
DNI?n
(where n=0 thru 9.
Returns the DNI
portion of 1 of 10
stored
configurations)
DNI=dddddddddddddd
ddddddddddtiiiiiiiiiiiiiiiiiiiiiii
iTL
(see Description of
Arguments)
(Returns current D&I
Configuration)
Drop & Insert
Configuration
(31 channels)
DIC=
67 bytes
Command or Query. (D&I++ only) (Not available in 600/L Emulation mode)
Sets or returns D&I++ in the form dddddddddddddddddddddddddddddddxxsssssssssssssssssssssssssssssssxxL where:
31 bytes of Drop Information (dddddddddddddddddddddddddddddddxx) where:
d=31 channels (bytes) defining Drop Timeslot information
PLUS xx=spares
31 bytes of Insert Information (sssssssssssssssssssssssssssssssxx) where:
s=31 channels (bytes) defining Insert Timeslot information
PLUS xx=spares
Typical for Drop or Insert Timeslot definition:
0=Unused
z=Timeslot 0 (zero)
1-9=Timeslots 1 through 9
A=Timeslot 10 through V=Timeslot 31
L=D&I Internal Loop: 0=OFF, 1=ON
EXAMPLE: <0/DIC=123456789ABCDEFGHIJKLMNOPQRSTUVxx123456789ABCDEFGHIJKLMNOPQRSTUVxx0
(Drop channels 1-32 using timeslots 1-31 and timeslot zero. Same for Insert. E1-CCS, Internal Loop Off.)
DIC=
DIC?
DIC*
DIC#
DIC?
DIC?n
(where n=0 thru 9.
Returns the DIC
portion of 1 of 10
stored
configurations)
DIC=dddddddddddddd
dddddddddddddddddxx
sssssssssssssssssssss
ssssssssssxxL
(see Description of
Arguments)
