CDM-625A Advanced Satellite Modem MN-CDM625A
Telnet Command Line Interface (CLI) Operation Revision 4
9–37
Hot
Key
Dialog Window Option Entry
C Request To Send
Use the ↑↓ arrow keys to select Loop No Action, Loop RTS Controls
Tx Output, or Ignore RTS Assert CTS
D HSSI Handshake Control
Use the ↑↓ arrow keys to select TA To CA Loop or RR Control CA TA
Control TxS
E Circuit ID Enter a Circuit ID value as needed
F
Carrier ID Use the
↑↓
arrow keys to select
Disable
or
Enable
G RTC Time Enter a value in the form HH:MM:SS
H RTC Date Enter a value in the form DD:MM:YY
I Tx Clock Source
Use the ↑↓ arrow keys to select Internal, Tx Terrestrial, Rx Loop
Timed, or Rx Sat
J Rx Clock Source
Use the ↑↓ arrow keys to select Rx Satellite, Tx Terrestrial, Internal
SCT, or Insert
K
Rx Buffer Size Enter a value from
16
to
32768
L Modem Reference Clock
Use the ↑↓ arrow keys to select:
•
Internal
•
External 1 MHz
•
External 2 MHz
•
External 5 MHz
•
External 10 MHz
•
Internal Plus Output
M G703 Clock Extend Mode Use the ↑↓ arrow keys to select None, Tx Lock, or Rx Enable
N
G703 Clock Extend Intf Use the
↑↓
arrow keys to select
T1
,
E1 Balanced
, or
E1 Unbalanced
O Warm Up Delay Use the ↑↓ arrow keys to select Disable or Enable
P
Warm Up Countdown Enter a value from
0
to
999
seconds
Q BERT Restart Monitor Use the ↑↓ arrow keys to select No or Yes
R
BERT Tx State Use the
↑↓
arrow keys to select
Off
or
On
S BERT Tx Pattern
Typical for either entry – Use the ↑↓ arrow keys to select:
•
BERT Pattern Space
•
BERT Pattern Mark
•
BERT Pattern 11
•
BERT Pattern 12
•
BERT Pattern 63
•
BERT Pattern 511
U BERT Rx Pattern
•
BERT Pattern 2047
•
BERT Pattern 2047 R
•
BERT Pattern MIL188
•
BERT Pattern 2^15
•
BERT Pattern 2^20
•
BERT Pattern 2^23
T BERT Rx State
Typical for each entry – Use the ↑↓ arrow keys to select Off or On
V
BERT 10^-3 Error Insert
W Recenter Buffer
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Modem
submenu.
