CDM-625A Advanced Satellite Modem MN-CDM625A
CDM-625A ODU (Transceiver, BUC, LNB) Operation Revision 4
10–9
10.3.3.2 (SELECT: MONITOR) Live-Alarms Menu
Live Unit=None Net=None
Alarms Rx=Demod Lock Tx=No Clock ()
Live BUC=None
Alarms LNB=None ()
Six alarm types are provided across two screens. The last two alarm types (on the second
screen) pertain to ODU operation as shown in the preceding examples.
Use the
▲▼ arrow keys to navigate between these read-only pages. The highest priority alarms
currently active for each of the ODU alarm types are as follows:
ALARM TYPE
BUC current
BUC voltage
BUC checksum or bad comms
BUC PLL
BUC temperature
LNB current
LNB voltage
