CDM-625A Advanced Satellite Modem MN-CDM625A
CDM-625A ODU (Transceiver, BUC, LNB) Operation Revision 4
10–18
Press ENTER or CLEAR after viewing any Monitor screen to return to the previous menu.
ODU: FSK-control  CSAT (2CSATs  CSAT #X)  Monitor  Tx
Tx: SynTune = 09.6 VDC Power = <24 dBm
IFLO = 11.1 VDC Temp = 26 C
ODU: FSK-control  CSAT (2CSATs  CSAT #X)  Monitor  Rx
Rx: SynTuneE = 01.4 VDC
IFLO = 11.2 VDC Temp = 26 C
ODU: FSK-control  CSAT (2CSATs  CSAT #X)  Monitor  Misc
Misc: Ref-Tune = 03.0 VDC
LNA = 00.05 mA Fan = 550 mA
ODU: FSK-control  CSAT (2CSATs  CSAT #X)  Monitor  Power-
Supplies
24V=24.1 VDC 12V=12.5VDC +5V=+5.4VDC
20V=21.2 VDC 10V=10.2VDC -5V=-5.3VDC
10.3.3.3.3.1.3 ODU: FSK-control  CSAT (2CSATs  CSAT #X)  Alarms
Alarms:
Current-Alarms Stored-Alarms ()
Use the
◄ ►arrow keys to select Current-Alarms or Stored-Alarms, and then press ENTER.
10.3.3.3.3.1.3.1 ODU: FSK-control  CSAT (2CSATs  CSAT #X) 
Alarms
Current-Alarms
Current Status: Tx = OK Rx = OK
Power-Supply = OK Misc = OK
This screen is read-only. Press ENTER or CLEAR to return to the previous menu.\
