CDM-625A Advanced Satellite Modem MN-CDM625A
CDM-625A ODU (Transceiver, BUC, LNB) Operation Revision 4
10–22
• AUTO mode – When the Online ODU faults, the switchover is done automatically to
replace the faulty unit.
If the ODU Redundancy system is in AUTO mode, a ‘forced switch-over’ can only
occur if the currently OFFLINE unit is fault-free.
• MANUAL mode – If selecting the mode as Manual, there is no automatic switchover if a
fault occurs.
To force a switchover to the other CSAT unit, use the
◄ ►arrow keys to select Switch: N, and
then use the
▲▼ arrow keys to select Y (Yes). Press ENTER when done.
10.3.3.3.3.3 ODU: FSK-control KST
KST Select:
Configuration Information Alarms ()
Use the
◄ ►arrow keys to select Configuration, Information, or Alarms, and then press ENTER.
10.3.3.3.3.3.1 ODU: FSK-control KST Configuration
KST Config:
Tx Rx Miscellaneous ()
Use the
◄ ►arrow keys to select Tx, Rx, or Miscellaneous, and then press ENTER.
10.3.3.3.3.3.1.1 ODU: FSK-control KST Configuration Tx
Tx:Off Freq=13955 MHz Att=23 dB
AGC=Off ()
Use the
◄ ►arrow keys to select Tx, Freq, Att, or AGC, and then use the ▲▼ arrow keys to
change that setting. Press ENTER when done.
10.3.3.3.3.3.1.2 ODU: FSK-control KST Configuration Rx
Rx: Freq=11950 MHz Att=20 dB Ref=087
Band=B ()
Note that Rx Band is not shown for the KST-2000A.
Use the
◄ ►arrow keys to select Freq, Att, Ref, or Band (KST-2000B only), and then use the
▲▼ arrow keys to change that setting. Press ENTER when done.
