Comtech EF Data CDM-625A - Page 500

CDM-625A Advanced Satellite Modem MN-CDM625A
CDM-625A ODU (Transceiver, BUC, LNB) Operation Revision 4
10–30
Use the ▲▼ arrow keys to view additional Current Alarm status screens. Press ENTER or CLEAR
to return to the previous menu.
ODU: FSK-control  BUC  Advanced-FSK  LPOD (2LPODs 
Online/Offline LPOD)
Stored-Events
As events are compiled, the Stored-Events screen appears as shown here:
Reading Stored Events.... Please Wait
Once all events are compiled, the Stored-Events screen appears as shown here:
Stored Events: Clear-All: No (No,Yes)
#084 Info - PWR ON 10/12/10 12:52:08
On the top line – Use the
◄ ►arrow keys to select between log entries and the Clear-All option.
To clear the Stored -Events Log, use the
▲▼ arrow keys to select Clear-All, and then use the
▲▼ arrow keys to select Yes. Press ENTER when done.
On the bottom line – To view the Stored-Events Log: With the cursor on the entry number, use
the
▲▼ arrow keys to scroll through the entries. Up to 512 entries are stored.
Each entry provides the following information:
Item
Comments
Entry Type
•
Info (Information)
• Fault
•
Clear (fault cleared)
Entry Number 001 through 511
Date
European Day-Month-Year (DD-MM-YY) format
Time
Hour:Minute:Second (HH:MM:SS) format
Description of the
fault/information
Example: Info – PWR ON
10.3.3.3.3.4.3.1.4 ODU: FSK-control  BUC  Advanced-FSK  LPOD
(2LPODs
 Online/Offline LPOD) Statistics
Statistics:
Config Stored-Statistics ()
Use the
▲▼ arrow keys to select Config or Stored-Statistics, and then press ENTER.
