Comtech EF Data CDM-625A - Page 532

CDM-625A Advanced Satellite Modem MN-CDM625A
CDM-625A ODU (Transceiver, BUC, LNB) Operation Revision 4
10–62
10.5.1.2.1.7 Home > Outdoor Unit (ODU) > CSAT-5060 > Redundancy
Open the Redundancy page from the nested CSAT-5060 submenu. Redundant ODU
configuration options are as follows:
Hot
Key
Dialog Window Option Entry
A Unit Red Force Switch Use the ↑↓ arrow keys to select No or Yes
B Unit Redundancy Mode Use the ↑↓ arrow keys to select Manual or Auto
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the nested CSAT-
5060 submenu.
10.5.1.2.1.8 Home > Outdoor Unit (ODU) > CSAT-5060 > Utilities
Open the Utilities page from the nested CSAT-5060 submenu. This page contains the following
options:
Hot
Key
Dialog Window Option Entry
A
Device Time Enter a time in the form
HH:MM:SS
B
Device Date Enter a date in the form
DD/MM/YY
The page additionally provides the model number, software version, and unit serial number of
the recognized ODU.
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the nested
CSAT-5060 submenu.
