CDM-625A Advanced Satellite Modem MN-CDM625A
Appendix D Revision 4
D–3
D.4 Configuring the CDM-625A for Carrier ID Operation
Carrier ID operation requires that you first enable Carrier ID feature operation, and then create
a MetaCarrier Custom Message. All other parameters (center frequency, symbol rate, and the
CDM-625’s MAC address) are set automatically. The CDM-625A provides several means for
configuring Carrier ID operation:
• Local Control via the CDM-625A Front Panel keypad and VFD.
• Remote Control with a user-supplied PC via the
o CDM-625A HTTP (Web Server) Interface using a compatible Web browser.
o Serial-based or Telnet-based Remote Control Interface using a terminal emulation
program or Windows Command-line.
o Ethernet-based Simple Network Management Protocol (SNMP) using a Network
Management System (NMS) and Management Information Base (MIB) File Browser.
USE OF THE SERIAL-BASED REMOTE CONTROL INTERFACE, THE TELNET-BASED
REMOTE CONTROL INTERFACE, AND THE ETHERNET-BASED SNMP INTERFACE ARE
RECOMMENDED ONLY FOR ADVANCED USERS. COMTECH EF DATA STRONGLY
ENCOURAGES USE OF THE CDM-625A FRONT PANEL OR HTTP (WEB SERVER)
INTERFACE FOR MONITOR AND CONTROL (M&C) OF THE CDM-625A.
D.4.1 Enabling Carrier ID Operation
D.4.1.1 Enabling Operation via the CDM-625A Front Panel and VFD
Sect. 6.2.6.3 Utilities: CarrID (Chapter 6. FRONT PANEL OPERATION)
From the front panel main (SELECT:) menu, use the ◄ ► arrow keys to select the Utility menu
branch, and then press ENTER. Then, from the Utilities: screen, use the ◄ ► arrow keys to
select the CarrID submenu. Press ENTER to continue (the flashing solid block indicates the
cursor position upon navigation to that display item):
SELECT: Configuration Test Monitor
Info Store/Ld Utility ODU FAST ()
Utilities: Set-RTC Display-Bright CarrID
LED Redundancy Circuit-ID Firmware Em
CarrierID:On (Off,On)For Tx>128ksps()
Latitude Longitude Telephone Message
