196 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 7
12.11 Variable selector 1 destination
12.31 Variable selector 2 destination
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range
Open-loop, Closed-loop vector, Servo,
Regen
Pr 0.00 to Pr 21.51
Default
Open-loop, Closed-loop vector, Servo,
Regen
Pr 0.00
Update rate Read on reset
12.12 Variable selector 1 output
12.32 Variable selector 2 output
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21 1 1
Range
Open-loop, Closed-loop vector, Servo,
Regen
±100.00 %
Update rate 4ms x number of menu 9 or 12 functions active write
12.13 Variable selector 1 source 1 scaling
12.33 Variable selector 2 source 1 scaling
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
311
Range
Open-loop, Closed-loop vector, Servo,
Regen
±4.000
Default
Open-loop, Closed-loop vector, Servo,
Regen
1.000
Update rate 4ms x number of menu 9 or 12 functions active read
12.14 Variable selector 1 source 2 scaling
12.34 Variable selector 2 source 2 scaling
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
311
Range
Open-loop, Closed-loop vector, Servo,
Regen
±4.000
Default
Open-loop, Closed-loop vector, Servo,
Regen
1.000
Update rate 4ms x number of menu 9 or 12 functions active read
