Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance
Feature look-
up table
Menus 15 to 17
SM-I/O Plus
Unidrive SP Advanced User Guide 269
Issue Number: 7 www.controltechniques.com
x.41 Analog input 1 scaling
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3111
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 4.000
Default
Open-loop, Closed-loop vector, Servo,
Regen
1.000
Update rate Background read
x.42 Analog input 1 invert
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default
Open-loop, Closed-loop vector, Servo,
Regen
0
Update rate Background read
x.43 Analog input 1 destination
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range
Open-loop, Closed-loop vector, Servo,
Regen
Pr 0.00 to Pr 21.51
Default
Open-loop, Closed-loop vector, Servo,
Regen
Pr 0.00
Update rate Read on reset
x.44
Analog input 2
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 1
Range
Open-loop, Closed-loop vector, Servo,
Regen
±100.0 %
Update rate Combined update time. This module adds 4ms to the combined update time.
x.45 Analog input 2 scaling
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3 111
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 4.000
Default
Open-loop, Closed-loop vector, Servo,
Regen
1.000
Update rate Background read
x.46 Analog input 2 invert
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default
Open-loop, Closed-loop vector, Servo,
Regen
0
Update rate Background read
