Control Techniques unidrive sp User Manual

Menus 15 to 17
SM-Applicat’ns
Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance
Feature look-
up table
290 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 7
Displays free CPU resource as current background execution time / 200ms x 100%
These parameters are the general setup parameters for the RS485 port. The following baud rate strings are defined:
x.04 Available system resource
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1
Default All drives 0
Range All drives 0 to 100
Update Rate Every 200ms
x.05 RS485 address ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default All drives 11
Range All drives 0 to 255
Update Rate Not Applicable
x.06 RS485 mode ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default All drives 1
Range All drives 0 to 255
Update Rate Not Applicable
x.07 RS485 baud rate ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Default All drives 4
Range All drives 0 to 9
Update Rate Not Applicable
Display Value Description
300 0 300 baud
600 1 600 baud
1200 2 1200 baud
2400 3 2400 baud
4800 4 4800 baud
9600 5 9600 baud
19200 6 19200 baud
38400 7 38400 baud
57600 8 57600 baud
115200 9 115200 baud
