Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance
Feature look-
up table
Menus 15 to 17
SM-Applicat’ns
Unidrive SP Advanced User Guide 291
Issue Number: 7 www.controltechniques.com
There will always be a finite delay between the end of a message from the host (master) and the time at which the host is ready to receive the
response from the application module (slave). The application module does not respond until at least 1ms after the message has been received from
the host allowing 1ms for the host to change from transmit to receive mode. This delay can be extended using Pr x.08 if required for both ANSI and
Modbus protocols.
This parameter allows a delay to be configured between enabling the RS485 transmitter and commencing transmission of data.
Control where the output of the DPL Print command is sent. The following strings are defined:
The scheduling rate for the user program clock task in milliseconds. A value of zero disables the clock task.
x.08 RS485 turnaround delay ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default All drives 2
Range All drives 0 to 255 ms
Update Rate Not Applicable
x.09 RS485 Tx enable delay ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default All drives 0
Range All drives 0 to 1 ms
Update Rate Not Applicable
x.10 DPL print routing ♣
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Default All drives 0
Update Rate Not Applicable
Display Value Description
SYPT 0 Print out sent to SYPT.
RS485 1 Print output sent to application module local RS485.
x.11 Clock tick time (ms)
Drive types Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default All drives 0
Range All drives 0 to 200
Update Rate Not Applicable
