Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance
Feature look-
up table
Menus 15 to 17
SM-SLM
Unidrive SP Advanced User Guide 305
Issue Number: 7 www.controltechniques.com
These parameters effectively give the position with a resolution of 1/2
32
ths of a revolution as a 48 bit number as shown below.
When the feedback device rotates by more than one revolution, the revolutions in Pr x.04 increment or decrement in the form of a sixteen bit roll-over
counter.
The marker offset corrects this position.
This parameter defines the mode of operation of the drive:
0 - HoSt: Host mode (Torque amplifier only)
1 - Enc.Only: Encoder only mode
Host mode uses an external position controller and an SM-SLM for the speed loop. The host controller will handle all SLM calculations for
initialisation. The UniSP acts as torque amplifier similar in operation as the MultiAx drive.
Enc. only mode uses the SLM module for speed feedback and nameplate data only.
x.04 Revolution counter
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111 1
Operating mode Host, Encoder only
Range Open-loop, Closed-loop, Servo, Regen 0 to 65,535 revolutions
Update rate 4ms write
x.05 Position
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111 1
Operating mode Host, Encoder only
Range Open-loop, Closed-loop, Servo, Regen
0 to 65,535 (1/2
16
ths of a revolutions)
Update rate 4ms write
x.06 Fine position
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111 1
Operating mode Host, Encoder only
Range Open-loop, Closed-loop, Servo, Regen
0 to 65,535 (1/2
32
ths of a revolutions)
Update rate 4ms write
47 32 31 16 15 0
Revolutions Position Fine position
x.07 Operating mode
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Operating mode Host, Encoder only
Range Open-loop, Closed-loop, Servo, Regen HoSt (0), Enc.Only (1)
Default Open-loop, Closed-loop, Servo, Regen HoSt (0)
Update rate Backgroud
