Unidrive SP Advanced User Guide 341
Issue Number: 7 www.controltechniques.com
Table 6-9 Parameter set-up to reproduce Macro 4 on a Unidrive SP
Parameter
Value
OL CL
7.10 Analog input 1 destination Pr 4.08
7.14 Analog input 2 destination Pr 1.36
8.22 T25 digital I/O 2 source / destination Pr 10.04
8.25 T28 digital input 5 destination Pr 10.33
8.26 T29 digital input 6 destination Pr 9.29 Pr 9.30
8.32 T25 digital I/O 2 output select On (1)
8.39 T28 & T29 digital input auto selection disable On (1)
9.04 Logic function 1 source 1 Pr 6.32
9.07 Logic function 1 source 2 invert On (1)
9.10 Logic function 1 destination Pr 7.09
9.33 T26 digital I/O 3 output select Pr 4.11
11.01 Define Pr 0.11 Pr 1.03
11.02 Define Pr 0.12 Pr 2.01
11.03 Define Pr 0.13 Pr 4.02
11.04 Define Pr 0.14 Pr 1.05
11.05 Define Pr 0.15 Pr 2.04
11.06 Define Pr 0.16 Pr 6.01
11.07 Define Pr 0.17 Pr 8.17
11.08 Define Pr 0.18 Pr 2.06
11.09 Define Pr 0.19 Pr 2.07
11.10 Define Pr 0.20 Pr 1.29
11.11 Define Pr 0.21 Pr 1.30
11.12 Define Pr 0.22 Pr 1.31
11.13 Define Pr 0.23 Pr 1.32
11.14 Define Pr 0.24 Pr 0.00
11.15 Define Pr 0.25 Pr 7.01
11.16 Define Pr 0.26 Pr 7.11
11.17 Define Pr 0.27 Pr 7.02
11.18 Define Pr 0.28 Pr 3.08
11.19 Define Pr 0.29 Pr 7.08
11.20 Define Pr 0.30 Pr 7.12
