Unidrive SP Advanced User Guide 353
Issue Number: 7 www.controltechniques.com
Table 6-15 Parameter set-up to reproduce Macro 7 on a Unidrive SP
Parameter
Default(
Ö)
OL CL
2.04 Ramp mode FASt
3.05 Zero speed threshold 2.0 2
5.27 Enable slip compensation OFF (0)
6.08 Hold zero speed On (1)
8.11 T24 I/O invert On (1)
8.21 T24 digital I/O source / destination Pr 9.01
9.04 Logic function 1 source 1 Pr 12.01
9.06 Logic function 1 source 2 Pr 9.02
9.07 Logic function 1 source 2 invert OFF (0) On (1)
9.14 Logic function 2 source 1 Pr 10.01 Pr 1.11
9.15 Logic function 2 output invert OFF (0) On (1)
9.16 Logic function 2 source 2 Pr 10.03
9.17 Logic function 2 source 2 invert On (1) OFF (0)
9.19 Logic function 2 delay 0.2
11.01 Define Pr 0.11 Pr 1.03
11.02 Define Pr 0.12 Pr 2.01
11.03 Define Pr 0.13 Pr 4.02
11.04 Define Pr 0.14 Pr 4.01
11.05 Define Pr 0.15 Pr 12.01
11.06 Define Pr 0.16 Pr 10.01
11.07 Define Pr 0.17 Pr 10.03
11.08 Define Pr 0.18 Pr 9.01
11.09 Define Pr 0.19 Pr 12.04
11.10 Define Pr 0.20 Pr 9.19
11.11 Define Pr 0.21 Pr 0.00
11.12 Define Pr 0.22 Pr 0.00
11.13 Define Pr 0.23 Pr 0.00
11.14 Define Pr 0.24 Pr 0.00
11.15 Define Pr 0.25 Pr 0.00
11.16 Define Pr 0.26 Pr 0.00
11.17 Define Pr 0.27 Pr 0.00
11.18 Define Pr 0.28 Pr 0.00
11.19 Define Pr 0.29 Pr 0.00
11.20 Define Pr 0.30 Pr 0.00
12.03 Threshold detector 1 source Pr 4.01
12.04 Threshold detector 1 level Pr 10.00
12.05 Threshold detector 1 hysterisis Pr 10.00
