Table 6-17 Parameter set-up to reproduce Macro 8 on a Unidrive SP
Parameter
Value
CL
2.02 Ramp enable OFF (0)
2.04 Ramp mode FASt
8.21 T24 digital I/O source / destination Pr 13.18
11.01 Define Pr 0.11 Pr 1.03
11.02 Define Pr 0.12 Pr 2.01
11.03 Define Pr 0.13 Pr 4.02
11.04 Define Pr 0.14 Pr 13.17
11.05 Define Pr 0.15 Pr 13.10
11.06 Define Pr 0.16 Pr 3.34
11.07 Define Pr 0.17 Pr 13.07
11.08 Define Pr 0.18 Pr 3.27
11.09 Define Pr 0.19 Pr 3.29
11.10 Define Pr 0.20 Pr 13.02
11.11 Define Pr 0.21 Pr x.05
11.12 Define Pr 0.22 Pr x.03
11.13 Define Pr 0.23 Pr x.10
11.14 Define Pr 0.24 Pr 13.09
11.15 Define Pr 0.25 Pr 13.12
11.16 Define Pr 0.26 Pr 13.13
11.17 Define Pr 0.27 Pr 13.14
11.18 Define Pr 0.28 Pr 6.01
11.19 Define Pr 0.29 Pr x.04
11.20 Define Pr 0.30 Pr 3.28
13.10 Position loop mode 1
