Datalogic Magellan 8500Xt

2-16 Magellan
TM
8500Xt Scanner
Dimensions
Model 8501
& Model 8502
Cutout
Model 8501
& Model 8502
Supports
20.125"
(51.12cm)
0.75"
(1.905cm)
18.625"
(47.308cm)
Rail
Rail
(Center Line)
11.625"
(29.53cm)
0.75"
(1.905cm)
Max. Radius = 0.25"
(0.635cm) 4x
20.125" ±0.06"
(51.2 ±0.15 cm)
18.625" ± .060"
(47.3 ±0.15 cm)
0.375" ± .030"
(0.952 ±0.07 cm)
0.375" ± .030"
(0.952 ±0.07 cm)
If leveling feet are needed
for models 8501 and 8502,
use the placement shown here,
represented with plus signs (+).
3.06" ± .006"
(7.77 ±0.15 cm)
3.06" ± .006"
(7.77 ±0.15 cm)
0.75"
(1.9 cm)
1.5"
(3.8 cm)
0.75"± .060"
(1.9 ±0.15 cm)
0.75"± .060"
(1.9 ±0.15 cm)
4.0"
(10.2 cm)
0.375" ± 0.03" (.95 ±.08 cm)
Liquid
Drainage
Liquid
Drainage
Figure 2-10
Model 8501
& Model 8502
Reference
Dimensions
26 lb.
(11.7kg)
Scanner/Scale
Weight
22 lb.
(10kg)
Scanner
Weight (w/o scale)
11.5"
(29.21cm)
11.25"
(28.58cm)
20.0"
(50.8cm)
5.0" (12.7cm)
7.0" (17.78cm)
12.0"
(30.5cm)
8.9"
(22.60cm)
Window
6.95"
(17.65cm)
. Models 8501 and 8502 Long Scanner or Scanning-Scale Reference Dimensions
