Dell S4048T User Manual

802.1X
802.1X is a port-based Network Access Control (PNAC) that provides an authentication mechanism to devices
wishing to attach to a LAN or WLAN. A device connected to a port that is enabled with 802.1X is disallowed
from sending or receiving packets on the network until its identity is verified (through a username and
password, for example).
802.1X employs Extensible Authentication Protocol (EAP) to transfer a device’s credentials to an
authentication server (typically RADIUS) using a mandatory intermediary network access device, in this case, a
Dell Networking switch. The network access device mediates all communication between the end-user
device and the authentication server so that the network remains secure. The network access device uses
EAP-over-Ethernet (EAPOL) to communicate with the end-user device and EAP-over-RADIUS to
communicate with the server.
NOTE
: The Dell Networking Operating System (OS) supports 802.1X with EAP-MD5, EAP-OTP, EAP-TLS,
EAP-TTLS, PEAPv0, PEAPv1, and MS-CHAPv2 with PEAP.
6
802.1X 114

Dell S4048T Specifications

General

Switching Capacity	1.44 Tbps
Rack Units	1U
Form Factor	Rack-mountable
Power Device	Internal power supply
Power Redundancy	Optional
Product Type	Switch
Jumbo Frame Support	Yes
Routing Protocol	OSPF, BGP, RIP, VRRP, PIM-SM, IGMP
Remote Management Protocol	SNMP, RMON, Telnet, SSH
Features	Quality of Service (QoS), Jumbo Frames Support, Virtual Route Redundancy Protocol (VRRP), VLAN support, sFlow, Multiple Spanning Tree Protocol (MSTP), Rapid Spanning Tree Protocol (RSTP), IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ae
Dimensions (W x D x H)	17.3 in x 16 in x 1.7 in
Operating Temperature	0°C to 40 °C
Operating Humidity	10% to 90% (non-condensing)
