Figure 317: Status Overview Tab
14.4 Storage Tab
The Storage tab consists of two sub-views: Storage Details and Unit Informations (Figure 318).
To access the Storage Tab, click on the green arrow on the right hand side of the GUI in the
MediaBlock and Status Overview tabs (Figure 314).
Storage Details, which is the top half of the screen, lists all the RAID builds configured
on the server. On the right side of the GUI, there is a visual representation of the
information for each RAID build in the first tab. The second tab has the Reset All Drives
button (see Section 15.3 for more information).
Unit Information, which is the bottom half of the screen, lists all the disks configured in
the selected RAID.
