Doremi IMS1000 - 23 Appendix F: Connection Diagram

IMS.OM.002949.DRM Page 301 of 310 Version 1.4
Doremi Labs
C
Theater
Automation
Interface
General Purpose
Input/Output
Auditorium
Management
Network Switch
IMS1000
Theater Complex Set Up
Auditorium
Auditorium
Auditorium
Auditorium
Auditorium
* For a stand-alone system. Not required if an external computer is used in a theater management system.
Digital Audio Processor
DLP Series 2
Projector
Computer*
Auditorium Set Up
Computer
TMS/LMS
Media Network
Switch
23 Appendix F: Connection Diagram
