6.9 Marriage
Once the projector and board have finished booting up, the lights on the side of the projector will
be red and green, indicating that the board and the projector are not married. The touch panel
controller attached to the projector will show a second error window, indicating that the marriage
has not occurred (Figure 83). Press the Acknowledge button.
Figure 83: Error Window
Go to Menu → Service Setup → IMB Marriage (Figure 84).
Figure 84: IMB Marriage
The marriage wizard, on the touch panel controller, will then guide you through the steps
necessary to complete the marriage. Click the Next button to begin (Figure 85).
