IMS.OM.002949.DRM Page 34 of 310 Version 1.4
Doremi Labs
4 Installation and Marriage with a NEC Series-2
Projector
Before you begin to install the IMS1000 into your projector, be sure that:
o The projector is powered down and in the off position.
o Disconnect the AC power cord from the wall.
o Remember to always follow ESD procedures.
4.1 Preparation
Figure 6: NEC Projector
Gently pull on the filter cover to remove it (Figure 7).
Figure 7: Remove Filter Cover
