IMS.OM.002949.DRM Page 295 of 310 Version 1.4
Doremi Labs
The behavior of the SM1 and SM2 LEDs is the following:
SM in FIPS lock (different color of SM2 can indicate the reason
for Fips lock, To Be Defined)
The behavior of the SM3 and SM4 LED is the following:
OK to play, no problem reported since last CPL validate
Service Door closed, but need to be rearmed
Service Door is open, marriage is activated otherwise
Service Door is open, Marriage is not activated
Marriage is initialized/armed but marriage not verified
Marriage is not initialized/armed, service door and physical
marriage are ok (ready to marry)
Marriage is not activated, physical marriage is currently broken
