Dynapac SD2500C - Page 109

D 11 23
Item Designation Brief description
44
Left auger
"MANUAL"
conveying direction
outwards
Pushbutton function:
- To manually trigger the conveying function for the left
half of the auger, conveying direction outwards.
A
For manual triggering, the auger function must be
switched to "AUTO" or "MANUAL"
A
On manual triggering, the automatic function is overrid-
den with reduced delivery capacity.
45
Right auger
"MANUAL"
conveying direction
outwards
Pushbutton function:
- To manually trigger the conveying function for the
right half of the auger, conveying direction outwards.
A
For manual triggering, the auger function must be
switched to "AUTO" or "MANUAL"
A
On manual triggering, the automatic function is overrid-
den with reduced delivery capacity.
46
Left auger
"MANUAL"
conveying direction
inwards
Pushbutton function:
- To manually trigger the conveying function for the left
half of the auger, conveying direction inwards.
A
For manual triggering, the auger function must be
switched to "AUTO" or "MANUAL"
A
On manual triggering, the automatic function is overrid-
den with reduced delivery capacity.
47
Right auger
"MANUAL"
conveying direction
inwards
Pushbutton function:
- To manually trigger the conveying function for the
right half of the auger, conveying direction inwards.
A
For manual triggering, the auger function must be
switched to "AUTO" or "MANUAL"
A
On manual triggering, the automatic function is overrid-
den with reduced delivery capacity.
