D 30 9
The protective roof is equipped with an additional front window and two side windows.
- The side windows can be swivelled out to the side at the sliding frame.
To close the side windows, press the latch (1) and pull the sliding frame with the
both straps (2).
- The front window can be swivelled using the handle (4) with the latch pulled (3).
To close the front window, pull the latch (4) and pull the sliding frame at the
handle (4).
Windscreen wiper
- Activate the windscreen wiper / screen wash on the operating panel if necessary.
A
Ensure that the washer fluid tank (5) is always adequately filled.
m
Replace worn wiper blades immediately.
Risk of crushing hands
When closing the spring-loaded front and side windows,
there is a risk of crushing which can cause injuries!
- Do not reach into the danger area.
- Set the latches correctly.
- Comply with further instructions in the safety manual.
