D 30 13
Driver's seat, type II
f
To avoid damage to health, the individu-
al seat settings should be checked and
adjusted before starting the vehicle.
f
After locking the individual elements, it
must no longer be possible to shift then
to another position.
- Weight setting (1): The relevant driv-
er's weight should be set by turning
the weight adjustment lever when the
driver's seat is unoccupied.
- Weight indicator (2): The set driver's
weight can be read off at the viewing
window.
- Longitudinal adjustment (3): Longi-
tudinal adjustment is released by actu-
ating the locking lever.
The locking lever must engage in the desired position.
- Seat height adjustment (4): The seat height can be individually adjusted. Turn the
handle in the desired direction to adjust the seat height.
- Backrest adjustment (5): The backrest inclination can be continuously adjusted.
Turn the handle in the desired direction to adjust.
- Armrest inclination (6): The armrest's longitudinal inclination can be adjusted by
turning the hand wheel. Turning outwards raises the front of the armrest; turning
inwards lowers it at the front.
In addition, the armrests can be folded up fully.
- Lumbar support (7): Both the height and the extent of the convexity in the backrest
padding can be individually adjusted by turning the hand wheel to the left or right.
- Seat belt (8): The seat belt must be applied before starting up the vehicle.
f
The seat belts must be replaced following an accident.
