Dynapac SD2500C - Extending the big ski

E 10 34
Extending the big ski
A
The big ski can be extended to both the
9 m and 13 m versions.
A
Structure of the 9 m version:
Extension part at the front/rear each.
Structure of the 13 m version:
Two extension parts at the front/rear
each.
- Place the extension module (1) onto
the centre element (2) and secure with
a bolt (3).
1
3
2
