1.4 Starting for paving
Set the switches, levers and controls listed below to the specified positions when the
screed has reached its operating temperature and a sufficient amount of material lies
in front of the screed:
- Push the drive lever (13) all the way to the front and start driving.
- Observe the distribution of the material and adjust the limit switches if necessary.
- Set the compacting elements (tamper / vibration) according to the required com-
paction ratio.
- Let the paving master check the paving thickness after 5–6 meters and correct if
necessary.
Carry out the check in the area of the caterpillar chains or drive wheels as the screed
tends to level an uneven ground. The reference points for the layer thickness are the
caterpillar chains or drive wheels.
The basic setting of the screed must be corrected when the actual layer thickness de-
viates significantly from the values indicated by the scales (see the operating instruc-
tions for the screed).
A
The basic setting is for asphalt material.
Item Travelling direction Position
13 Drive lever Centre position
73 Travel drive fast/slow Tortoise-operating speed
15 Travel drive preselector Mark 6-7
63
Preparation for screed floating posi-
tion
LED ON
67 Vibration LED ON
66 Tamper LED ON
52/53
Auger left/right Auto
123
48/49
Conveyor left/right Auto
127
126 /
130
Levelling Auto
Speed regulation, vibration Depending on the working conditions
Speed regulation, tamper Depending on the working conditions
