D 30 4
Ladder
The ladder is used to access the control
platform.
The ladder can be secured in the top po-
sition:
- have the ladder raised by a second
person. Set the latch (1) on both sides
of the ladder to the intended position.
f
The ladder must not be locked when
driving or paving!
Storage space
There are two removable containers (2)
under the lockable bottom flap.
A
For storing the on-board tool kit, remote
controls and other attachments.
A
The fuse and terminal box is beneath the
metal containers.
