D 30 17
Screed lock, hydraulic (o)
A
The screed locks must additionally be
extended on both sides of the vehicle
prior to transportation with the screed
lifted.
f
Transportation with an unsecured
screed leads to a risk of accidents!
- Lift the screed.
- Activate the function on the operating
panel.
A
The two screed locks (1) extend hydrau-
lically.
m
ATTENTION!
Insert screed lock only at crown adjustment "zero"!
Screed lock only for transportation!
Do not enter or work under screed only secured with screed lock for transportation!
Danger of accidents!
